Disc Mill

Disc Mill yog dab tsi?

Disc zeb yog ib hom crusher uas siv tau los zom, txiav, txiav, shred, fiberize, pulverize, granulate, tawg, rub, curl, fluff, twist, hull, blend, los yog refine. Nws ua haujlwm zoo ib yam li lub pob zeb Buhrstone thaum ub nyob rau hauv uas cov khoom noj yog pub ntawm qhov tawm tsam discs lossis daim hlau. Cov discs yuav grooved, serrated, los yog spiked.

Qhov zoo ntawm Disc Mill

Muaj peev xwm

Plaub inlet li qub los sib tov thiab zom koj cov noob tib lub sijhawm. Peev xwm txawv ntawm 1, 000 mus rau 12, 000 kg / h rau nplej.Optimal mill muaj peev xwm los ntawm Augers zaus tswj qhov system.

Kev siv hluav taws xob tsawg

Powerfull electric engine.Tshwj xeeb tsuas yog 5kWh ib tonne hauv av, kom ntseeg tau tias cov nqi txo qis dua lub neej ntawm koj cov khoom siv.

Durability

Txhua txheej ntawm cov discs tuaj yeem zom 10,000 - 25,000 tonnes ntawm cov nplej kom txog thaum cov khoom seem xav tau, nyob ntawm qhov loj ntawm lub zeb.Disc mills cov khoom siv tau raug kuaj kom ze li 3x nyuaj li. ib txwm rauj mills ua kom lub neej ntev.

Tsawg suab nrov

Lub zog hluav taws xob muaj zog.Lub suab nrov zoo ib yam li lub tswb moos ringing, piv rau ib txwm zeb zeb yog lub tshuab hluav taws xob.

Tsev 12 3 Rau sab kawg 1/3

Vim Li Cas Xaiv Peb

Hoobkas

Peb lub tuam txhab npog thaj tsam ntawm 15,000km2, suav nrog thaj chaw tsev ntawm 6,000km2. Peb muaj ntau tshaj 100 tus neeg ua haujlwm.

24 teev online pabcuam

Peb zoo siab los pab peb cov neeg siv khoom txhua lub sijhawm raws li peb tau mob siab rau thiab ua haujlwm hnyav pab pawg ua haujlwm 24 teev.

Kev paub txuj ci nplua nuj

Peb cov neeg ua haujlwm yog qee qhov kev paub dhau los hauv kev lag luam, muab cov lus qhia kom raug thiab cov kev daws teeb meem, kom ntseeg tau tias peb muab peb cov neeg siv khoom nrog kev txawj ntse thiab kev pabcuam.

Universal Coarse Crusher For Medicinal Herbs

Kev tswj xyuas nruj

Txhua lub tshuab ua haujlwm nruj nruj ntawm lub Hoobkas kom paub meej tias cov tshuab peb muab tau raws li ib qho ntawm cov qauv siab tshaj plaws.

Hom Disc Mill

Ib-disc zeb:

Ib qho disc mills muaj nyob rau hauv qhov ntau thiab tsawg 24 "mus rau 52" rau kev siv nrog cov motors xws li 25 HP txog 1000 HP. Tes log phaj qhov sib txawv hloov kho (tus qauv), nrog rau kev xaiv lub cev muaj zog tswj kev hloov kho muaj nyob rau ntawm qee cov qauv, V-siv tsav nrog nyiaj siv ua haujlwm-lub cev muaj zog. (1000 HP chav tsev yog pem teb mounted nkaus xwb), Pem hauv ntej viav vias qhov rooj nkag, Packing-gland ncej ntsaws ruaj ruaj, cam khwb cia thiab fabricated tsim, ceev-tso phaj unloading, Lub ntiajteb txawj nqus los yog mechanical pub, Muaj nyob rau hauv carbon los yog stainless hlau

Ob chav disc mills:

Ob chav disc mills muaj nyob rau hauv qhov ntau thiab tsawg 24 "mus rau 36" siv nrog cov motors xws li 200 HP txog 500 HP. Ob-disc / ob-lub cev muaj zog kev npaj tso cai rau cov neeg siv horsepower muab faib rau txhua qhov kawg ntawm lub zeb, them nyiaj ntau dua ntawm HP.Available nyob rau hauv carbon los yog stainless hlau, V-siv tsav nrog xaiv nyiaj siv ua haujlwm lossis pem teb lub cev muaj zog, zawv zawg bearing phaj gap hloov, Caij nplooj ntoos hlav-loaded packing seals, ceev-tso phaj unloading.

Cov txheej txheem los txo kev hnav ntawm Disc Mill

Kev hnav ntau dhau yuav ua rau muaj kev sib tsoo tsis zoo thiab nce kev siv tus nqi ntawm kev sib tsoo disc, yog li peb sim txo qhov hnav ntawm cov khoom sib tsoo hauv kev siv.Qhov teeb meem ntawm kev puas tsuaj rau kev sib tsoo chamber ntawm disc grinder tsis yog kom tus neeg siv txo qhov tus naj npawb ntawm cov sij hawm siv, tab sis yuav tsum xyuam xim rau ntau yam hauv kev siv niaj hnub, ces kev puas tsuaj rau lub disc grinder yuav zam tau.

Ua ntej ntawm tag nrho cov, nyob rau hauv cov nqe lus ntawm qhov luaj li cas, piv txwv li thiab loading peev xwm ntawm lub disc zeb, qhov zoo ntawm lub disc zeb yuav hloov nrog qhov loj me. Ntawm ib qho ceev ntawm lub pob zeb, qhov zoo dua ntawm cov pob zeb sib tsoo, qhov cuam tshuam ntau dua. Thaum teeb tsa qhov loj ntawm cov khoom sib tsoo, qhov sib tsoo qhov tshwm sim ntawm cov khoom sib tsoo ntawm tib qhov loj dua, thiab cov khoom sib tsoo yog qhov ua rau qaug zog hnav, thiab kev thauj khoom ntawm cov khoom sib tsoo yuav cuam tshuam rau kev sib tsoo ntawm cov khoom sib tsoo. .

Kev ua haujlwm ntawm cov disc grinder yog tsawg. Lub ntsiab tseem ceeb cuam tshuam rau nws cov kev ua tau zoo tshaj plaws yog qhov kev sib hloov ntawm cov ncej tsav tsheb tsawg dhau, uas ua rau muaj qhov hnyav hnyav thiab tsim kua muag los ntawm lub zog tsis txaus. Yog tias qhov kev ncua deb ntawm qhov sib tsoo disc me dhau, nws yuav cuam tshuam rau qhov ntws. Yog tias qhov no tshwm sim, peb yuav tsum nce qhov kev ncua deb kom ntau li ntau tau nyob rau hauv qhov chaw.

Tom qab ntawd xav txog cov khoom ntawm cov khoom siv hauv av los ntawm lub tshuab disc. Lub hardness, brittleness, cov duab thiab qhov loj ntawm cov khoom muaj ib qho tseem ceeb heev cuam tshuam rau cov txheej txheem sib tsoo chamber.

Txoj Cai Ua Haujlwm ntawm Disc Mill

Cov khoom noj nkag mus rau hauv cov plua plav pov thawj los ntawm lub hopper filling thiab yog pub rau nruab nrab ntawm ob ntsug sib tsoo discs. Ib qho txav sib tsoo disc tig tawm tsam ib qho ruaj khov thiab kos rau hauv cov khoom noj. Qhov tsim nyog comminution cuam tshuam yog tsim los ntawm lub zog thiab kev sib txhuam. Cov txheej txheem txheej txheem sib tsoo disc meshing thawj cov qauv ua ntej crushing; centrifugal quab yuam ces txav nws mus rau thaj tsam sab nraud ntawm kev sib tsoo discs qhov chaw zoo sib xws. Cov qauv ua tiav tawm los ntawm qhov sib tsoo qhov sib txawv thiab tau sau rau hauv lub receiver. Qhov sib txawv ntawm qhov sib tsoo disc yog hloov kho tsis tu ncua thiab tuaj yeem hloov kho thaum lub sijhawm ua haujlwm hauv thaj tsam ntawm 0.1 thiab 5 hli; muaj ib qho kev soj ntsuam ntxiv qhov rais rau kev kuaj xyuas qhov chaw sib txawv.

Disc Mill Tshuab Structure

Nws siv hydraulic kis tau tus mob, muaj cov qauv yooj yim thiab ua haujlwm yooj yim. Lub ntsiab ncej yog txhawb rau ntawm ob fulcrums. Thaum lub phaj txav rotates, nws axial kev taw qhia bears lub siab ua hauj lwm ntawm hydraulic tsav. Hydraulic roj muaj zog elasticity. Raws li lub siab ntawm cov khoom yuav tsum tau hloov hauv av, qhov sib txawv ntawm qhov txav thiab ruaj daim hlau kuj hloov me ntsis, uas yooj yim rau kev sib cais ntawm fibers.

Qhov sib txawv ntawm lub phaj ruaj tuaj yeem hloov kho, thiab qhov sib txawv ntawm cov phaj ruaj khov yog pom tau los ntawm kev qhia valve ntawm hydraulic system. Qhov sib txawv loj yog tso tawm los ntawm qhov ntsuas hluav taws xob, uas yooj yim thiab raug. Thaum tus tsav lub valve tsis ua haujlwm, lub tes tuav, lub iav iav thiab lwm yam khoom siv kuj tuaj yeem siv los ua kom paub qhov kev hloov pauv ntawm cov ntawv txav thiab ruaj khov.

Cov dej foob thiab cov dej txias tuaj yeem tshem tawm cov cua sov uas tsim los ntawm cov khoom sib tsoo hauv lub sijhawm kom tsis txhob muaj qhov deformation ntawm lub tes tsho hnav-tiv taus, kub kub ntawm cov roj bearing thiab hlawv ntawm cov ntim. Lub luag haujlwm ntawm cov khoom foob dej yog los tiv thaiv cov tawv nqaij hauv cov khoom sib tsoo los ntawm kev nkag mus rau sab ntawm cov kabmob pem hauv ntej.

Teem lub electro-hydraulic interlocking tiv thaiv system uas cuam tshuam cov roj twj tso kua mis lub cev muaj zog thiab lub ntsiab lub cev muaj zog, ntsaws cov dej siab micro hloov thiab lub ntsiab lub cev muaj zog, lubricating roj micro hloov thiab lub ntsiab lub cev muaj zog, thiab lubricating roj kub micro hloov thiab lub cev muaj zog. Txhawm rau kom muaj kev ua haujlwm zoo ntawm lub tshuab disc.

Cov ntawv pov thawj

Nrog kev nplua nuj kev paub thiab zoo ib yam, khaws tsim nyog rau Tuam Tshoj Enterprise nrog "AAA" credit rating thiab daim ntawv cog lus ua raws, dhau ISO9002 nyob rau hauv 2003 tau txais CE daim ntawv pov thawj nyob rau hauv 2010, ib txwm coj cov hmoov thiab granules khoom lag luam nrog kaum ob patents.

202310161329403de0bbfa22bf4ffb959228028455554d

20231016133027240a79082f394dd18cd04547b7117764

2023101613295571696040792140a1ae31969a474e6f94

20231016133003255085987b2440c78f7e9be7dda125ad

202310161329595545e804d73248c5ae1c04561b9724e6

20231016133031fc44a3b3c06a4df3a91e1046fcb5cd53

Peb lub Hoobkas

Peb lub tuam txhab npog thaj tsam ntawm 15,000km2, suav nrog thaj chaw tsev ntawm 6,000km2. Peb muaj ntau tshaj 100 tus neeg ua haujlwm.

FAQ

Q: Lub hauv paus ntsiab lus ua haujlwm ntawm disk zeb yog dab tsi?

A: Cov khoom yog kos los ntawm kev sib tsoo disk los ntawm centrifugal rog, uas yog qhov zoo li qub sib tsoo disk txuas nrog lub hau (stator) thiab ceev ceev rotating disk nyob hauv qab ntawm cov vaj tse sib tsoo.

Q: Dab tsi yog qhov zoo ntawm disk zeb?

A: Cov mills disc yog tsim rau kev sib tsoo ntawm ntau yam sib txawv ntawm cov ntaub ntawv raw, nrog rau cov pellets nrog txoj kab uas hla mus txog 12 hli. Ib qho ntawm qhov zoo ntawm cov zeb disc yog tias nws muaj peev xwm sib txawv ntawm kev sib tsoo thaum lub sijhawm ua haujlwm, thiab tom qab ntawd ua kom zoo dua cov qauv los pub cov tsiaj sib txawv.

Q: Dab tsi yog qhov mechanism ntawm disk zeb?

A: Cov khoom yog hauv av los ntawm lub siab thiab shearing txiav txim ntawm ob counteracting sib tsoo disks nrog ntxhib interlocking hniav. Cov khoom siv hauv av cia li poob los ntawm kev sib tsoo ua ntej rau hauv cov tub rau khoom sau.

Q: Dab tsi yog qhov txawv ntawm lub tshuab rau cov menyuam thiab lub tshuab disc?

A: Qhov siab dua qhov nrawm, lub sijhawm sib tsoo luv dua thiab qhov zoo dua qhov grist, tab sis ntau dua lub zog noj. Txawm hais tias siv ceev ceev, lub disc zeb muaj lub zog siv ntau dua li ob-yob zeb, tab sis lub sij hawm sib tsoo luv dua thiab cov malt finer.

Q: Lub peev xwm ntawm lub tshuab disc yog dab tsi?

A: Disc mills yog ib qho nruab nrab 10% kev siv hluav taws xob ntau dua li rauj zeb thiab tuaj yeem ua tiav lub peev xwm ntawm 6 tons / teev. Cov cav tov uas muaj peev xwm txog li 24 tons / teev yog muaj raws li qhov kev thov.

Q: Dab tsi yog lub tshuab disc siv rau?

A: Lub tshuab disc yog ib hom crusher uas tuaj yeem siv los zom, txiav, txiav, txiav, fiberize, pulverize, granulate, tawg, rub, curl, fluff, twist, hull, blend, los yog ua kom zoo.

Q: Yuav ua li cas yog lub disc attrition zeb ua hauj lwm?

A: Hauv attrition milling, abrasive rubbing action presses cov ntaub ntawv ntawm ob counter-rotating, hlau discs. Cov ntaub ntawv nkag los ntawm cov khoom nkag mus rau hauv nruab nrab ntawm cov discs thiab centrifugal quab yuam coj lawv sab nraud thiab thaum kawg los ntawm cov discs kom tawm mus, hauv av mus rau qhov xav tau qhov loj me.

Q: Dab tsi yog disc zeb pulverizer?

A: Hom pulverizer no feem ntau hu ua Disk Pulverizer lossis Disk Mill thiab tuaj yeem siv rau kev sib tsoo thiab tsis tu ncua zoo sib tsoo ntawm cov ntaub ntawv nyuaj-nkig thiab nruab nrab-nyuaj hauv kev lag luam mining thiab metallurgy, iav kev lag luam, kev lag luam ceramics. . Zoo tagnrho rau kev npaj cov qauv ua ntej kuaj lawv.

Q: Ob hom mills yog dab tsi?

A: Ob hom qauv ntawm milling yog qhuav milling thiab ntub milling qhov twg qhuav milling siv particle rau particle sib cuag thaum ntub milling suspends cov ntaub ntawv nyob rau hauv ib tug slurry. Muaj ntau hom mills, thiab cov ntaub ntawv ua tiav los ntawm lawv.

Q: Dab tsi yog daim ntawv thov ntawm disc zeb hauv kev lag luam zaub mov?

A: PUC perforated disc mills yog siv rau crushing lumpy khoom pieces thiab mashing cov ntaub ntawv xws li txiv hmab txiv ntoo, zaub thiab nqaij, rau pre-comminution ntawm soy taum thiab feem ntau rau zus tau tej cov khoom noj khoom haus, tshuaj thiab tshuaj pleev ib ce thiab cov khoom. comminution ntawm soaked ntawv.

Q: Lub tshuab tuaj yeem siv rau dab tsi?

A: Lub tshuab zeb yog ib qho khoom siv, feem ntau yog cov qauv, lub tshuab lossis cov khoom siv hauv chav ua noj, uas ua rau cov khoom tawg me me los ntawm kev sib tsoo, crushing, los yog txiav. Xws li kev sib koom ua ke yog ib qho tseem ceeb hauv chav ua haujlwm hauv ntau cov txheej txheem. Muaj ntau ntau hom mills thiab ntau hom khoom ua tiav hauv lawv.

Q: Dab tsi yog qhov txawv ntawm lub tshuab txiav thiab lub tshuab txiav disc?

A: Qhov txawv ntawm lub kaum sab xis thiab lub tshuab txiav disc yog dab tsi? Qhov ntau yam, lub kaum ntse ntse zoo yog tsim rau kev siv xws li txiav, sib tsoo, polishing thiab sharpening. Conversely, lub disc cutter yog ib tug me me, ib leeg-tes txiav hniav uas yog zoo tshaj plaws haum rau lub teeb txiav daim ntaub ntawv.

Q: Koj puas tuaj yeem sib tsoo nrog txiav disc?

A: Tsis yog! Txiav-tawm lub log yog rau kev txiav ntawm qhov chaw ib puag ncig nkaus xwb. Vim li cas? Txiav-tawm lub log yog nyias los ntawm kev tsim thiab tsis muaj lub zog txaus rau sab sib tsoo.

Q: Puas tuaj yeem ua hlau txiav disc txiav pob zeb?

A: Hauv qee txoj kev, koj tuaj yeem txiav cov pob zeb nrog cov hlau txiav disc. Tab sis koj yuav pom tias muaj qhov sib txawv loj hauv qhov kev ua tau zoo. Vim hais tias ib tug concretecutting disc muaj silicon-carbide abrasive. Thaum cov hlau txiav disc yuav muaj zirconia lossis aluminium oxide, nyob ntawm seb lawv yuav siv rau.

Q: Puas yog kev sib tsoo discs tas sijhawm?

A: Yog vim li cas txiav thiab sib tsoo discs muaj lub txee lub neej yog tias cov resin uas siv los khi cov khoom siv disc ua ke tawg dhau sijhawm raws li nws nqus dej los ntawm qhov chaw. Qhov no txhais tau hais tias ib qho tsis tu ncua disc tuaj yeem tawg thaum siv, nrog cov khoom ntse raug tshem tawm ntawm qhov ceev heev.

Q: Dab tsi yog 4 hom kev sib tsoo tshuab?

A: Cov tshuab sib tsoo poob rau hauv tsib pawg: ntog grinders, cylindrical grinders, centerless grinders, internal grinders thiab tshwj xeeb. Surface grinders yog siv los tsim cov chaw tiaj tus, angular thiab tsis sib xws.

Q: Vim li cas cov grinder discs tawg?

A: Cov tshuab tsis zoo. Loose log spindle, dhau qhov kawg ua si, thiab xoob lossis vibrating tshuab qhov chaw xws li lub rooj ua haujlwm thiab cov neeg tuav haujlwm yuav ua rau lub log khoov hauv kev txiav thiab tawg.

Q: Dab tsi yog lub hom phiaj ntawm lub tshuab milling?

A: Rolling mills yog siv los yob kub los yog txias ferrous los yog non-ferrous strips, xov hlau thiab txawm rods. Nyob ntawm seb hom zeb nws tuaj yeem siv rau kub lossis txias tawg thiab ua tiav ntawm bar, ntawv lossis sawb. Lawv tuaj yeem siv los ua kom tiav dov ntawm nyias gauge Tshuag, embossing lossis compacting.

Q: Kuv puas xav tau lub tshuab dov?

A: Rolling yog ib qho tseem ceeb ntawm cov txheej txheem hlau vim nws tso cai rau koj txo cov thickness ntawm koj cov hlau thiab tshem tawm cov kev hloov pauv uas yuav ua rau lawv tsis sib xws. Tau kawg, qhov no tsis tuaj yeem ua tiav los ntawm tes, yog li koj yuav xav tau lub pob zeb txhim khu kev qha uas ua haujlwm rau koj thiab koj lub hom phiaj.

Q: Lub tshuab sib tsoo ua haujlwm li cas?

A: Nyob rau niaj hnub no, lawv feem ntau yog siv hluav taws xob. Kev sib tsoo ntawm cov khoom siv tau tshwm sim los ntawm cov khoom siv dag zog uas rhuav tshem cov qauv los ntawm kev kov yeej lub zog sib txuas sab hauv. Tom qab kev sib tsoo lub xeev ntawm cov khoom tau hloov pauv: qhov loj ntawm cov nplej, qhov loj ntawm cov nplej thiab cov nplej.

Peb yog cov kws tshaj lij disc zeb tuam ntxhab thiab cov muag khoom hauv Suav teb txij li xyoo 1989, tshwj xeeb hauv kev muab cov khoom lag luam zoo thiab cov kev pabcuam. Peb sov siab txais tos koj mus yuav los yog lag luam wholesale customized disc zeb ua nyob rau hauv Suav teb nov los ntawm peb lub hoobkas.
