Pharma Granules Ua Tshuab
kev taw qhia
Pharma Granules Ua Tshuab nrog Dry Granulation tshuab yog ib qho tseem ceeb ntawm cov khoom siv hauv kev lag luam kws tshuaj siv los ua cov hmoov nplej rau hauv cov granules. Tsis zoo li ntub granulation, uas yuav tsum tau ua kua binders, lub qhuav granulator compacts hmoov nyob rau hauv lub siab siab los ua slugs los yog nplooj ntawv, uas yog ces tawg mus rau hauv granules.
Lub ntsiab mechanism ntawm lub granulator qhuav yog nws cov menyuam compaction system. Lub tshuab siv ob lub txee-rotating rollers los ntim cov hmoov rau hauv daim ntawv tuab lossis slug. Cov txheej txheem no tshem tawm qhov xav tau ntawm cov dej noo lossis cov kua nplaum, ua rau nws haum rau cov dej noo- cov ntaub ntawv rhiab heev.
Pharma Granules Ua Tshuab - Qhuav Granulator yog ib qho khoom siv tseem ceeb hauv kev tsim tshuaj niaj hnub. Nws muaj peev xwm los tuav cov ntaub ntawv rhiab heev, ua kom cov txheej txheem ntau lawm, thiab tsim cov khoom zoo - zoo granules yam tsis xav tau cov dej noo ua rau nws muaj txiaj ntsig zoo hauv kev tsim cov tshuaj ntsiav tshuaj thiab tshuaj ntsiav. Nws muaj kev ua tau zoo, kev ua kom muaj peev xwm, thiab tus nqi- ua tau zoo, ua rau nws mus- daws cov tuam txhab tshuaj thoob ntiaj teb.
Txoj cai ua haujlwm
Lub hauv paus ntsiab lus ua haujlwm ntawm Pharma Granules Ua Tshuab - Cov Granulator Qhuav yog nyob ib ncig ntawm cov txheej txheem ntawm granulation qhuav, qhov twg hmoov cov khoom xyaw yog compacted rau hauv granules yam tsis siv cov dej noo. Qhov no muaj txiaj ntsig tshwj xeeb rau cov dej noo-sensitive lossis tshav kub- cov khoom xyaw tshuaj rhiab heev. Lub Dry Granulator siv lub hauv paus ntsiab lus ntawm cov menyuam compaction los ua granules, muab ib qho qhuav, binder - pub dawb rau lwm txoj hauv kev ntub dej granulation. Cov txheej txheem no ua kom muaj kev tsim khoom zoo thiab siab - cov khoom siv tshuaj zoo.
Technical parameters
|
Qauv |
Muaj peev xwm ntau lawm (kg / h) |
Qhov ntau thiab tsawg (mm) |
Ua haujlwm siab (kn) |
Lub cev muaj zog (kw) |
Zuag qhia tag nrho Dimensions (L * W * H) |
Qhov hnyav (kg) |
|
GK-70 |
20-100 |
0.5-3 |
198 |
11.1 |
1600*1000*2230 |
2000 |
|
GK-100 |
50-150 |
0.5-3 |
297 |
11.8 |
1560*1000*2230 |
2200 |
|
GK-120 |
60-200 |
0.5-3 |
294 |
13.8 |
1560*1000*2230 |
2500 |
|
GK-200 |
80-300 |
0.5-3 |
310 |
25 |
2150*1250*2700 |
3500 |
fAQ
1. Q: Pharma Granules Ua Tshuab yog dab tsi?
A: Pharma Granules Ua Tshuab yog lub tshuab tsim los hloov cov hmoov zoo rau hauv granules yam tsis tas siv cov dej noo los yog kua binders. Cov txheej txheem granulation feem ntau cuam tshuam cov hmoov rau hauv slugs lossis cov khoom siv compacted, uas yog tom qab ntawd milled rau hauv granules. Txoj kev no yog qhov zoo tagnrho rau cov dej noo- cov ntaub ntawv rhiab heev.
2. Q: Dab tsi yog qhov txawv ntawm granulators qhuav thiab ntub granulatorst?
A: Lub granulator qhuav tsis siv cov kua binder. Cov hmoov yog compacted thiab ces muab tso rau hauv granules. Cov granulator ntub dej siv cov tshuaj binder los tsim cov granules thiab tom qab ntawd tshem tawm cov dej noo los ntawm kev ziab. Cov granulators qhuav yog qhov kev xaiv zoo tshaj rau cov dej noo-sensitive thiab tshav kub- cov ntaub ntawv rhiab heev, thaum siv cov granulators ntub dej, cov khoom muaj zog dua los yog tswj cov porosity yog qhov tsim nyog.
3. Q: Puas yog Pharma Granules Ua Tshuab ua raws li kev cai tshuaj?
A: Yog lawm, kev tsim cov granulators qhuav feem ntau ua raws li GMP cov lus qhia thiab FDA / EMA cov cai rau cov khoom siv tshuaj. ISO 9001 Kev Tswj Xyuas Txheej Txheem Zoo.
